The V25 100mm Fluid Head from Camgear is designed for EFP and field-based HD production and studio applications. It supports most portable broadcast cameras and camcorders in heavy-configuration and studio applications with teleprompter or compact studio lenses. The V25P fluid head features an eight-step pan & tilt drag, including “zero” position. The selectable ten-position counterbalance system allows for fine adjustments. This fluid head offers 100mm ball leveling and is equipped with a mini Euro plate quick-release system for fast camera setup.

Camera Plate Features – Quick Release
Camera Plate Type – Mini Euro Plate
Camera Mounting Screw – 1x 1/4″-20 Male & 1 x 3/8″-16 Male
Balance Plate Sliding Range – 4.7″ / 120 mm

Base Mount – 100 mm Half Ball
Counter Balance – Incremental 10-Step
Bubble Level – 1x Illuminated

Drag Control – 8-Step
Vertical Tilt – +90° to -75°
Panning Range – 360°

Load Capacity – 57.3 lb / 26 kg
Operating Temperature – -40 to 140°F / -40 to 60°C
Weight – 12.3 lb / 5.6 kg

The Cartoni Focus 22 Fluid Head features a 100mm ball base and supports loads between 6.6 to 48.5 lb, with perfect balance along its entire +/-90° tilt range. Relatively lightweight at 8.6 lb, it is intended for users who usually shoot with light loads and therefore need a lightweight head, but who sometimes need to add on a heavy lens or accessory.

Camera Plate Features – Quick Release
Camera Plate Type – Euro Plate

Drag Control – Continuous
Drag Type – Fluid
Vertical Tilt – +90° to -90°
Panning Range – 360°

Load Capacity – 48.5 lb / 22 kg
Operating Temperature 0 -40 to 140°F / -40 to 60°C
Weight – 8.6 lb / 3.9 kg

The Cartoni Focus HD Video Tripod Head is compatible with 100mm bowl base tripods, and supports cameras weighing up to 26 lbs. Featuring a continuously variable fluid damping system on both pan and tilt movements and a patented variable counterbalance, the unit can be used with all existing ENG (Electronic News Gathering) and DV cameras. The lightweight (4.4 lbs) tripod head is easy to carry.

Camera Plate Features – Sliding Balance Plate
Base Mount – 100 mm Half Ball
Counter Balance – Continuous

Drag Control – Continuous
Vertical Tilt – +90° to -90°
Panning Range – 360°
Load Capacity – 26 lb / 12 kg
Weight – 4.4 lb / 2 kg

The Oconnor Ultimate 1030D Fluid Head Is a lightweight fluid head that shares features with the other fluid heads in the OConnor Ultimate fluid head line. This allows operators to easily transition between lighter and heavier cameras without having to relearn think about the differences between fluid heads. The head supports 30 pounds worth of camera and accessories at a C.O.G. (center of gravity) 6 inches above the camera platform. The counterbalance system helps prevent the camera from tilting forward or back on the head on its own, and to remain in the position the operator places it without requiring additional effort to hold it in place. The counterbalance system on the 1030D is a stepless system, so it is continuously variable from the maximum weight the head can support all the way down to zero. This makes the 1030D extremely versatile, and suitable for use with heavy ENG style cameras all the way down to lightweight cameras, while maintaining the same operational feel.

Camera Plate Features – Sliding Balance Plate
Base Mount – 100 mm Half Ball
Counter Balance – Continuous
Bubble Level – 1x Illuminated

Drag Control – Tilt: Continuous/ Pan: Continuous
Vertical Tilt – +90° to -90°
Panning Range – 360°
Independent Pan Lock – Yes
Independent Tilt Lock – Yes
Load Capacity – 30 lb / 13.6 kg
Weight – 8.7 lb / 3.9 kg

With its 8.8 lb capacity and compact size, the Sachtler FSB 4 Fluid Head is ideal for supporting small handheld camcorders and video-enabled DSLRs. As the only head in its class to feature Sachtler’s Sideload mechanism, the FSB 4 boasts an exceptionally large sliding range of 4.7″. Along with a 5-step counterbalance, this ensures extremely quick and precise balancing. At the same time, no-compromise vibration damping allows for extremely subtle and finely graded movement.

Camera Plate Features – Quick Release, Sliding Balance Plate
Camera Plate Type – Sideload Plate S

Base Mount – 75 mm Half Ball
Counter Balance – Incremental 3-Step

Drag Control – Tilt: 3-Step
Vertical Tilt – +90° to -70°
Panning Range – 360°
Independent Pan Lock – Yes
Independent Tilt Lock – Yes

Load Capacity – 8.8 lb / 4 kg
Operating Temperature – -40 to 140°F / -40 to 60°C
Weight – 5.3 lb / 2.4 kg

The Sachtler Video 20 Fluid Head incorporates a wider payload range and a faster, simpler balancing system. The increased range means that even lightweight cameras–such as video DSLRs–can be used effectively on this head, aided by a 16-step counterbalance system that allows for fine degrees of tuning. Like its predecessor, the Video 20 S1 can also easily handle heavier ENG and EFP camcorders, with a Boost Button now included for sudden shifts in payload range (for example, when switching out a shoulder-mount camera for a handheld HDV camcorder or DSLR).

Camera Plate Features – Sliding Balance Plate, Quick Release
Camera Plate Type – Touch & Go Plate 16
Balance Plate Sliding Range – 4.7″ / 120 mm

Base Mount – 100 mm Half Ball
Counter Balance – Incremental 16-Step
Bubble Level – 1x Illuminated

Drag Control – Tilt: 7-Step Plus 0
Vertical Tilt – +90° to -70°
Panning Range – 360°
Independent Pan Lock – Yes
Independent Tilt Lock – Yes

Load Capacity – 55 lb / 25 kg
Operating Temperature – -40 to 140°F / -40 to 60°C
Weight – 7.5 lb / 3.4 kg
